STAGE.I Oil Cooler + Impact Frame Package
Ok… We have some GOOD NEWS & BAD NEWS;
BAD NEWS First; this last batch of High Flow Impact Bars sold out faster than we expected, and the next batch won’t be ready by the end of June.
GOOD NEWS; For those who pre-order now, I will offer FREE SHIPPING on all Stage.I Oil Cooler Package PRE ORDERS. Deal Ends June 15th. Please email me at info@griffin-motorsports.com if interested in this special deal.
If you cannot wait until then, I think Dedicated Motorsports still have (2-3) of them left in stock. As a token of our appreciation, I will provide a $100 discount off our oil cooler when you share proof of purchase of a crash bar from DMS between now, and the end of June.
Until then… stay classy!
As you may already know, it’s easy for oil temps to skyrocket on the LT4 platform on the street and at the race track with many seeing oil temps at or near 300F, which can be an engine killer. One issue with the OEM oil cooler was the decision to cool the oil using your engine coolant. This is not only ineffective on hard track days, but it should be obvious that 250F + coolant and the 250F + engine oil, will essentially heat each other as things get spicier and spicier.
The solution? The GMS remote oil cooling package + High Flow Impact Bar Bundle. There are many factors that make our kit the best on the market for your LT platform. Let’s run through them together shall we?
To start, we separate the oil and coolant by removing the OEM oil cooler all together, and replace the undersized OEM unit with a much larger 22” x 5” x 2.5” dual pass, bar plate unit made by our friends at CSF. It includes built in -10AN male fittings and a classy matte black heat rejecting finish that coordinates perfectly with our High Flow Impact Bar. In fact, this ultra-effective cooler hides perfectly behind the upper portion of the grill and flow-tie thanks to a custom bracket which puts it out of view.
From there, the next big consideration is oil delivery. With your OEM cooler out of the way, we can now install the Improved Racing block of plate. This unit is not only absolutely gorgeous, but it fits perfectly, and includes the -10AN bosses that you need to run proper AN lines and fittings.
The next consideration is temperature control. Our solution is another Improved Racing piece of art, by way of their High Flow inline thermostat. The beauty of this unit lies in it’s ability to allow a very small amount of oil to pass through when closed, which helps bring the stored oil within the cooler to a similar temperature, preventing cold oil, from shocking the system when the thermostat opens. Our kits include a 185F thermostat. Head to the Improved Racing website for a 215F if you prefer.
Improved Racing maintains exceptionally high quality-control standards. Every single Improved Racing thermostat undergoes rigorous inspection, functional testing, and certification before it leaves their doors. They manufacture all of them in the USA to the strictest standards and back them with a lifetime warranty – your guarantee of lasting performance and peace of mind. This is just one of the reasons we partnered with the team at Improved Racing for these two critical components. Because your car deserves the best.
Bringing them all together is a pair of braided -10AN hose and all of the AN fittings you will need for a super clean and efficient system. We also provide you with a high quality block off kit that allows you to remove the all of the OEM oil cooler lines for a cleaner look, buy installing one 5/8” hose cap and one 5/8” anodized aluminum quick lock cap.
Note; based on the size and location of this #8066 bar and plate cooler, we recommend this option for street cars up to 950hp and track cars up to 750hp. Making more power than that? then we recommend you consider our larger Stage.II oil cooler package that includes larger 12AN lines, a larger oil cooler that holds 30% more fluid, and repositions the cooler to the main grill opening for better airflow / heat rejection.
On our 900hp test car with a Katech oil pump we saw no change in oil pressure before and after the oil cooler installation. Hot idle before and after ranges from 31.5 - 33.5psi. 6000k + RPM at WOT ranges from 60 - 75psi depending in the gear you are in. No change after the cooler was installed. Note, we did change from 0-40W oil to 5-50W oil for street use, and recommend 15w-50 for track use.
Our goal was to not only provide you with the best turn-key oil cooling system on the market, but to save you over $450 on parts when purchased as a bundle. We are confident that you will love the design and performance of this Stage.I oil cooling package.
What’s in the box;
GMS High Flow Impact Bar Assembly (optional)
Improved Racing Block Off Plate (with hardware)
CSF Dual Pass Oil Cooler (with -10AN male fittings)
Raceflux -10 AN Fittings & Braided Hose (extra length)
GMS OEM Oil Cooler Delete Kit and Installation Instructions
Improved Racing High Flow In-line Thermostat (optional)
GMS Brackets to mount direct to the OEM Crash Bar (optional)
(2) 12" lengths of 2,000F Thermal Wrap to protect from headers.
What YOU will need to provide;
Motor Oil (this kit will add approx. 2.0 additional quarts) (we use 5W-50 weight)
Patience and attention to detail for installation... or, someone like that, who you trust with your beloved, adorned, magnificent, earth shaking, alarm sounding ZL1.
Fitment: 2018-2024 Camaro ZL1.
Impact Bar Install Guide can be downloaded by clicking THIS link.
Oil Cooler Install Guide can be downloaded by clicking THIS link.
