AEM X-Series OBD.II Wideband
By popular request, we finally offering the popular AEM X-Series Wideband to our product line, to help compliment our best selling Banks iDash PRO!
AEM's X-Series OBDII Wideband UEGO AFR Sensor Controller Gauge (PN 30-0333) provides tuners who are using piggyback tuning modules or open source software with the ability to view AFR through the factory CAN-bus stream that is output by the factory ECU, and deliver the most accurate, safe and powerful tune. The 30-0333 X-Series OBDII Wideband Gauge is verified to work with HPTuners and DashDaq, with more applications being validated. The X-Series Wideband AFR OBDII Gauge includes an OBDII connector and Bosch 4.9LSU sensor that can be free-air calibrated or used with the factory resistor calibration. Additional wiring for a 0-5v or RS232 Serial output can be added by the user for outputting to a data logger. This OBDII pass-through capability replaces the traditional AEMnet stream available in the 30-0300 X-Series Wideband AFR Gauge Controller.
The AEM X-Series is widely known for being the Fastest Wideband’s on the market having been previously tested against 17 other wideband systems. The UEGO air/fuel high speed controllers ensure no loss of signal fidelity and full transient response, making it able to identify the slightest fluctuations in AFR and output them in full value.
AEM KEY FEATURES
X-Series Wideband UEGO AFR Controllers Gauge were fastest responding wideband air/fuel ratio controllers in an independent test vs. 17 competitors wideband AFR controllers
Patented X-Digital wideband technology (Patent 9,575,030)
Includes Bosch 4.9LSU wideband UEGO sensor
Factory calibrated resistor does not require free-air calibration, but technology allows for free-air calibration as sensor ages if user desires
Compatible with vehicle/system voltages up to 16V
0-5V & RS232 output for data logging and feedback control, AEMnet (CANbus) for data logging and daisy-chaining multiple controllers up to 16 cylinders
Can display AFR values in hundredths of %
52mm gauge diameter and slim 0.825" gauge depth
Gauge cup depth only .200" deep
Auto dimming feature
User configurable display via buttons on the gauge face for changing AFR values, Lambda and O2%, and 3- or 4-digit display
Black bezel and black dual faced faceplate included (gauge only, silver bezel/white gauge option sold separately, PN 30-0300-ACC)
Whats in the box;
(1) AEM 03-0334 Wideband + OBD.II Pass-through Connector
Let’s face it, we expect a lot from our cars, and spend a lot of time trying to squeeze every last HP from them. You deserve to have the very best data, delivered in the very best set of high performance gauge’s on the market.
